Software Defined Storage Solutions

Highly Reliable, Unified Storage Solution for Enterprises

Supermicro and Open-E storage solutions allow enterprise IT departments to transform their storage infrastructure, increase flexibility and agility, simplify management and dramatically reduce costs without compromising availability, reliability, or functionality.

Running on world-class server hardware, Supermicro and Open-E storage solutions deliver unified file and block storage services, and extremely powerful data protection capabilities.

Supermicro and Open-E storage solutions are ideally suited to support demanding enterprise applications in physical or virtual infrastructure, high performance media applications, and large-scale archive repositories

Why Open-e Data Storage Software?

  • Reliable and award-winning storage application containing powerful storage  features for an affordable price
  • Excellent compatibility with industry standards: recognizes most industry standard hardware and automatically installs drivers for RAID controllers, FC-HBAs or Ethernet cards
  • Easy to deploy and manage  thanks to an intuitive, web-based interface
  • The most stable developed using agile methodologies with continuous integration updates and extensive QA testing
  • Excellent technical support: 1 year Basic Support for free
  • Optimized performance with high data throughput and I/O
  • Scale-out architecture allowing users to expand capacity online, without disruption and compromising performance
  • Field-proven reliability with over 30,000  installations in 100+ countries



Storage Portfolio

Home NAS

HN-MT4E2SP

System Specifications:

  • CPU: Intel Xeon E-2224 (4Core, 3.4 GHz, 8M)
  • Memory: 8 GB DDR4 Memory, Up to 32GB unbuffered non-ECC SO-DIMM
  • OS Drive: 1 x 240GB SATA3 Enterprise SSD
  • Storage: Up to 32 TB RAW Storage
  • NIC: 4 x 1GbE LAN Ports
  • Remote Management:  IPMI 2.0/ KVM over LAN / Media over LAN
  • Power:  250W Bronze Level Power Supply

NAS Feature:

  • NFS, SMB/CIFS, FTP, AFP (NAS)
  • iSCSI (SAN)
  • NIC Teaming/Bonding
  • Software RAID 0, 1, 5, 6
  • Up to 4 Network Cards (max. 1GbE)
  • Initial FREE 4TB storage capacity
  • Up to 36TB supported storage
  • Additional Support available



Small Business NAS

SBN-28E2RP

System Specifications:

  • CPU: Intel Xeon E-2224 (4Core, 3.4 GHz, 8M)
  • Memory: 8 GB DDR4 2666MHz Memory, Up to 128GB Unbuffered ECC UDIMM
  • OS Drive: 2 x 240GB SATA3 Enterprise SSD
  • Storage: Up to 36 TB RAW Storage
  • NIC: 4 x 1GbE LAN Ports
  • Power Supply Unit: 720W 1U Redundant Power Supply

NAS Feature:

  • NFS, SMB/CIFS, FTP, AFP (NAS)
  • iSCSI (SAN)
  • NIC Teaming/Bonding
  • Software RAID 0, 1, 5, 6
  • Up to 4 Network Cards (max. 1GbE)
  • Initial FREE 4TB storage capacity
  • Up to 36TB supported storage
  • Additional Support available



BS-212SRP



System Specifications:

  • Intel Xeon Bronze 3204 Processor (6Core, 1.9GHz, 8.25M)
  • 16 GB DDR4 2933MHz Memory, Up to 2TB DDR4 2933MHz ECC RDIMM
  • SAS3 (12Gbps) via Broadcom® 3008 SW controller; RAID 0, 1, 10
  •  OS Drive:  2 x 240GB Enterprise SATA3 SSD
  •  Up to 168 TB SAS/ SATA RAW Space
  •  Dual JBOD Expansion Port
  •   Disk Scale up: Up to 63 Disk (with optional JBOD)
  •  2 x 10GBase-T & 2 x 1GbE LAN Ports
  •  Remote Management:  IPMI 2.0/ KVM over LAN /  Media over LAN
  •  Power Supply Unit: 800W Redundant Power Supplies Titanium Level (96%)

Storage Feature:

  • 10GbE NFS, SMB/CIFS,
  • FTP, Secure FTP, HTTP, Apple Talk
  • 10GbE iSCSI (SAN)
  • NIC Teaming/Bonding
  • SNMP
  • Logical Volume Replication over Ethernet
  • Online Logical Volume Expansion
  • Online RAID Capacity Expansion
  • Synchronous Volume Replication over LAN
  • Asynchronous Data (File) Replication over LAN and WAN
  • iSCSI Failover
  • Backup Agent
  • iSCSI/NFS Active-Active Failover (Optional)
  • iSCSI/NFS Active-Passive Failover
  • NAS(NFS) Failover
  • SW RAID 0,1,5,6 / HW RAID  0,1,5,6,10,50,60

Business Storage

BS-424E2RP

System Specifications:

  • CPU: Intel Xeon E-2224 (4Core, 3.4 GHz, 8M)
  • Memory: 32 GB DDR4 2666MHz Memory, Up to 128GB ECC UDIMM
  • RAID: SAS3 (12Gbps) via Broadcom® 3108 controller;
  • OS Drive:  2 x 240GB Enterprise SATA3 SSD
  • Storage: Up to 196 TB SAS/ SATA RAW Space
  • JBOD: Dual JBOD Expansion Port
  • Disk Scale up: Up to 63 Disks (with optional JBOD)
  • NIC: 6 x 1GbE LAN Ports
  • Remote Management:  IPMI 2.0/ KVM over LAN / Media over LAN
  • Power Supply Unit: 1280W Redundant Titanium Level power supplies

Storage Feature:

  • iSCSI (SAN), NFS (NAS), SMB/CIFS,
  • FTP, Secure FTP, HTTP, Apple Talk
  • NIC Teaming/Bonding
  • SNMP
  • Logical Volume Replication over Ethernet
  • Online Logical Volume Expansion
  • Online RAID Capacity Expansion
  • iSCSI Failover
  • Backup Agent
  • iSCSI/NFS Active-Active Failover (Optional)
  • iSCSI/NFS Active-Passive Failover
  • NAS(NFS) Failover
  • SW RAID 0,1,5,6 / HW RAID  0,1,5,6,10,50,60
  • S.M.A.R.T- monitoring system for Hard Disk Drive Failure
  • Remote Access Console
  • CLI & Web UI
